Sized at less than 20" deep for ideal back bar use
SUMMIT's SCR7012DB is a commercial beverage merchandiser designed to maximize impulse sales.
This commercially approved all-refrigerator utilizes automatic defrost for low maintenance, with a digital thermostat for easy temperature control. Adjustable chrome shelves on a cantilevered system let you customize the hammered aluminum interior to accommodate different sized items. Full interior lighting ensures an attractive product display.
Two solid glass doors are trimmed with stainless steel and equipped with front-mounted locks for added security. Both are self-closing to help ensure stored items aren't accidentally left exposed to room temperature. Stainless steel handles complete the professional look. This unit comes with a textured black cabinet finish.
This model is ETL-S listed to NSF-7 commercial standards. Set this unit above or below the counter (with proper ventilation) as a self-service refrigerator for impulse buys.
|
Overview
|
| Height of Cabinet |
34.13" (87 cm) |
| Width |
35.5" (90 cm) |
| Depth |
19.63" (50 cm) |
| Depth with Handle |
21.13" (54 cm) |
| Depth with door at 90° |
36.0" (91 cm) |
| Capacity |
7.4 cu.ft. (210 L) |
| Defrost Type |
Automatic |
| Door |
Glass |
| Cabinet |
Black |
| US Electrical Safety |
ETL |
| Canadian Electrical Safety |
ETL-C |
| Sanitation |
ETL-S |
| Amps |
1.2 |
| Voltage/Frequency |
115 V AC/60 Hz |
| Weight |
150.0 lbs. (68 kg) |
| Shipping Weight |
150.0 lbs. (68 kg) |
| Parts & Labor Warranty |
1 Year |
| Compressor Warranty |
5 Years |
| UPC |
761101054223 |
|
Refrigerator Features
|
| Door Swing |
French |
| Shelf Type |
Chrome |
| Shelf Qty |
4 |
| Adjustable Shelves |
Yes |
| Thermostat Type |
Digital |
| Fan Type |
Interior |
| Refrigerant Type |
R600a |
| Refrigerant Amount |
1.92oz. |
| High Side PSI |
215.0 |
| Low Side PSI |
60.0 |
| Interior Light |
Yes |
|
Dimensions
|
| Interior Height |
28.25" (72 cm) |
| Interior Width |
32.5" (83 cm) |
| Interior Depth |
15.0" (38 cm) |
| Compressor Step Height |
7.5" (19 cm) |
| Compressor Step Width |
32.5" (83 cm) |
| Compressor Step Depth |
7.25" (18 cm) |
| Exterior |
| PH - Probe Hole |
Alarm/Thermometer - Factory-installed alarm with external temperature readout |
|
| Door |
| T4F Door Tint |
T3F Door Tint |
| T2F Door Tint |
T1SF Door Tint |
|
Automatic defrost
Reduced maintenance with auto defrost system
Commercially approved
ETL-S Approved to ANSI-NSF Standard 7 for use in commercial establishments
Two glass doors
Solid glass doors provide a clear view of interior contents
Two factory installed locks
Protect contents in both sections with a key lock on each door
Adjustable shelves
Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Digital thermostat
Electronic controls located in the front kickplate for easy temperature management
Interior light
Illuminates the interior for a an attractive view of stored contents
Stainless steel trim on doors
Added touch of elegance with a stainless steel door trim
Fully finished textured black cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
