Convertible design allows ducted or ductless installation to best meet your home's needs
Made in North America, Summit's HC series under cabinet convertible range hoods offer versatile ventilation solutions for every kitchen space.
Model HC20SS is a 20" wide range hood ideal for apartments and other smaller kitchens. It comes in a stainless steel finish with a horizontal grain constructed from 21 gauge galvanized steel for lasting durability. The powerful 2-speed fan is easily managed by a rocker switch with a high and low setting. This unit can operate at 270 CFM for thorough ventilation. Airflow is directed upwards at a slight angle, ensuring smoke and odors won't blow towards the home chef.
This hood ships for ductless/recirculating ventilation (where no exhaust connection to the outside is available) but is convertible for horizontal or vertical ducted ventilation (3 1/4" x 10" rectangular ducting or 7" round, transition required). We include a combination aluminum mesh/charcoal filter to absorb grease, smoke, and odors. This unit accepts a standard light bulb (not included). Both the filter and lens cover snap in place, with no tools required to change out as needed. Note: this hood does not include a power cord and is designed to be hard-wired by a licensed professional.
In addition to this range hood, Summit manufactures this series in additional colors, as well as shell hoods, wall-mounted European hoods, and island hoods in a range of styles. Browse the full Summit product line to explore your options.
|
Overview
|
| Height of Cabinet |
5.5" (14 cm) |
| Width |
20.0" (51 cm) |
| Depth |
20.0" (51 cm) |
| Cabinet |
Stainless Steel |
| US Electrical Safety |
UL |
| Canadian Electrical Safety |
ULC |
| Amps |
1.7 |
| Voltage/Frequency |
115 V AC/60 Hz |
| Weight |
11.0 lbs. (5 kg) |
| Shipping Weight |
30.5 lbs. (14 kg) |
| Parts & Labor Warranty |
1 Year |
| UPC |
761101087054 |
|
Range Hood
|
| Installation |
Under Cabinet |
| Venting |
Convertible |
| Controls |
Dial |
| Number of Fan Speeds |
2 |
| Maximum Air Movement |
270.0 CFM |
| Sone Rating |
6 |
| Duct Shape |
3"1/4" x 10" rectangular or 7" round |
Under cabinet range hood
Low profile design offers classic style to finish your kitchen
20 inch width
Sized for use over 20 inch cooking surfaces (additional sizes available)
Convertible design
Can be used for ducted venting to the outside or recirculating ventilation where no external venting is possible
Stainless steel finish
Real stainless steel with a horizontal grain for a clean, professional look
Easy conversion
Ships pre-set for recirculating mode but can be converted in a few simple steps
Versatile top or rear exhaust
Can be connected to 3 1/4" x 10" vertical or horizontal exterior venting or 7" round vertical (transition required for both)
Powerful ventilation
Can operate at 270 CFM to ensure thorough ventilation of your cooking surface
Angled airflow
Vents are set at a slight upwards angle, ensuring smoke and odors won't be directed towards the user
Durable 21 gauge steel construction
Stainless steel exterior with a body that's 53% heavier gauge than most of the industry's under cabinet hoods
Two-speed fan
High and low setting to allow proper ventilation of your kitchen as needed
Accepts a standard bulb
Designed to hold a standard incandescent light bulb with easy installation and no tools required
Combination charcoal/aluminum mesh filter
Aluminum filter includes charcoal filler to absorb smoke, grease, and odors for a cleaner kitchen experience
Removable filter
Snap-in design allows you to easily remove the filter for fast replacing as needed
Rocker switch controls
Front-located on/off and high/low switches make it easy to manage the light and fan
Professional installation
Designed to be hard-wired by a licensed professional
Made in North America
TAA compliant
