Perfectly designed for built-in installation under lower ADA compliant counters
SUMMIT's collection of built-in undercounter wine cellars offers quality storage with user-friendly convenience and elegant style.
The SWC1840BADA is a 32" high wine cellar designed for built-in or freestanding use under lower ADA compliant counters, with a unique 18" width. The reversible glass door features an elegant stainless steel trim and professional handle, with a factory installed lock for added security.
Inside, this auto defrost wine cellar can store up to 34 Bordeaux or Burgundy style bottles, with a slotted floor that can also accommodate champagne if needed. The slide-out wooden shelves come in a jet black finish for a modern look. Recessed LED lighting offers an elegant view of the items, while the digital thermostat ensures easy temperature management.
With its slim fit and convenient design, the SWC1840BADA makes an attractive addition to any room.
|
Overview
|
| Height of Cabinet |
31.38" (80 cm) |
| Width |
17.75" (45 cm) |
| Depth |
23.5" (60 cm) |
| Depth with door at 90° |
39.75" (101 cm) |
| Capacity |
3.3 cu.ft. (93 L) |
| Bottles |
34 bottles |
| Defrost Type |
Automatic |
| Door |
Glass |
| Cabinet |
Black |
| US Electrical Safety |
ETL |
| Canadian Electrical Safety |
ETL-C |
| Sanitation |
ETL-S |
| Amps |
1.25 |
| Voltage/Frequency |
115 V AC/60 Hz |
| Weight |
95.0 lbs. (43 kg) |
| Shipping Weight |
120.0 lbs. (54 kg) |
| Parts & Labor Warranty |
1 Year |
| Compressor Warranty |
5 Years |
| UPC |
761101056197 |
|
Wine Cellar
|
| Number of Zones |
1 |
| Door Swing |
RHD |
| Reversible |
Yes |
| Adjustable Shelves |
Yes |
| Shelf Type |
Wood |
| Shelf Qty |
5 |
| Thermostat Type |
Digital |
| Interior Light |
Yes |
| Fan Type |
Interior and Exterior |
| Refrigerant Type |
R600a |
| Refrigerant Amount |
10.6 oz. |
| High Side PSI |
150.0 |
| Low Side PSI |
50.0 |
| Level Legs |
4 |
| Temperature Range |
41º to 68ºF |
| Sound Level |
33.8 dB |
| Exterior |
| SSK - Stainless steel kickplate |
LHD - Left hand door swing |
| Latch - Factory-installed door latch requires manual release to open unit |
|
| Door |
| T4 Door Tint |
T3 Door Tint |
| T2 Door Tint |
T1S Door Tint |
| T1 Door Tint |
|
Commercially approved
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
ADA compliant
32" height is designed to fit under lower ADA compliant counters
Built-in capable
Make the best use of space by installing your appliance under the counter
34 bottle capacity
Versatile interior can store up to 34 standard 750ml Bordeaux style or wider Burgundy style bottles
Glass door with stainless steel trim
Provides a full display of stored contents with a heat-safe double tempered design
Factory installed lock
Keyed security on the door
Digital thermostat
Electronic controls for precise temperature management.
Digital display
Temperature readout can be shown in Celsius or Fahrenheit
LED lighting
Gentle illumination with an on/off switch
Automatic defrost
Reduced maintenance with the convenience of auto defrost
Wooden shelves
5 shelves offer the perfect storage for wine bottles in a classic wooden finish
Reversible door
Keep your options flexible with a reversible door that is easy to switch when your arrangement changes
Professional handle
Stainless steel look for added elegance
Flush back
Space saving design
Fully finished black cabinet
Allows the unit to be used freestanding
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
